Vibration is the oscillatory motion of a body about its equilibrium position. In mechanical engineering, understanding how vibrations are classified and what basic elements create a vibratory system is essential for machine design, condition monitoring, and failure prevention.
Classification of Vibration
Vibrations are classified based on cause, nature of motion, energy dissipation, and predictability.
1. Based on Excitation
Free Vibration: Occurs when a system vibrates after an initial disturbance with no continuous external force.
Example: a plucked cantilever beam.Forced Vibration: Occurs due to a continuous external force.
Example: engine-induced vibration in a machine frame.
2. Based on Energy Dissipation
Undamped Vibration: No energy loss; amplitude remains constant (ideal case).
Damped Vibration: Energy is lost due to friction or resistance; amplitude decreases with time.
3. Based on Linearity
Linear Vibration: Restoring force is proportional to displacement (follows Hooke’s law).
Nonlinear Vibration: Restoring force is not proportional to displacement.
4. Based on Predictability
Deterministic Vibration: Can be predicted exactly (known excitation).
Random Vibration: Cannot be predicted precisely (earthquakes, wind gusts).
5. Based on Mode of Deformation
Longitudinal Vibration: Particles move parallel to the axis.
Example: vibration of a rod.Transverse Vibration: Particles move perpendicular to the axis.
Example: vibration of a beam.Torsional Vibration: Twisting motion about the axis.
Example: rotating shafts.
6. Based on Degrees of Freedom (DOF)
Single Degree of Freedom (SDOF): Motion described by one coordinate.
Multi Degree of Freedom (MDOF): Requires multiple coordinates.
Continuous System: Infinite DOF (beams, plates).
7. Based on Time Response
Transient Vibration: Exists for a short time after excitation.
Steady-State Vibration: Continues as long as excitation exists.
Elements of a Vibratory System
Any vibratory system can be modeled using three fundamental elements:
1. Mass (m)
Represents the inertia of the system.
Stores kinetic energy.
Resists acceleration.
Examples: machine components, flywheels, rotors.
2. Stiffness (k)
Provided by springs or elastic members.
Stores potential energy.
Provides restoring force.
Examples: springs, beams, shafts, rubber mounts.
3. Damping (c)
Represents energy dissipation.
Reduces vibration amplitude over time.
Examples: dashpots, material internal friction, lubricated contacts.
Simple Vibratory Model (SDOF)
A basic vibratory system consists of a mass–spring–damper arrangement:
Mass (m) attached to a spring (k)
Damper (c) connected in parallel
Displacement (x(t)) describes motion
The equation of motion is:
[
m\ddot{x} + c\dot{x} + kx = F(t)
]
Where (F(t)) is the external force (zero for free vibration).
Importance in Engineering
Understanding vibration classification and elements helps in:
Designing machines to avoid resonance
Selecting proper vibration isolators
Diagnosing faults in rotating machinery
Improving comfort and safety
Enhancing structural life
