Mechanical- Engineering Drawing

Avatar

Team EveryEng

Mechanical Engineering

View profile
language_ic

Language

English
views_ic

1881 Views

people_ic

54 Enrollments

share_ic

Share

infinite_ic

Access anytime

duration_ic

2200 Min

info_ic

This course format through pre-recorded video. You can buy and watch it to learn at any time.

FREE

prerecorded_session_ic
videos
banner

Why do you enroll

Key topics covered

Course details

Course tags

Course content

Why do you enroll

Unlock the language of engineering with the Engineering Drawing NPTEL course! Learn to communicate complex ideas and designs with clarity and precision. Master the fundamentals of drawing, orthographic projections, and CAD software to:

- Enhance your design skills and creativity

- Improve your communication with engineers, manufacturers, and clients

- Increase your productivity and efficiency in design and development

- Stay competitive in the industry with industry-standard CAD skills

Show more

down_ic

Key topics covered

- Mastering the fundamentals of engineering drawing

- Enhancing design skills and creativity

- Improving communication with stakeholders

- Increasing productivity and efficiency

- Gaining industry-standard CAD skills

- Staying competitive in the industry

- Opening doors to new opportunities and career advancement

Course Details

This course provides a comprehensive introduction to the principles and practices of engineering drawing, including:

1. Fundamentals of drawing: Understanding drawing instruments, scales, and conventions

2. Orthographic projections: Creating and interpreting multiview drawings (top, front, side, etc.)

3. Isometric and oblique drawings: Creating and interpreting 3D drawings

4. Sectional views: Creating and interpreting sectional drawings

5. Dimensioning and tolerancing: Understanding dimensioning systems and tolerancing methods

6. Assembly and detail drawings: Creating and interpreting assembly and detail drawings

7. Computer-aided design (CAD): Introduction to CAD software and drawing technique.

Source: nptelhrd (Youtube Channel)
Engineering Drawing by Dr. Anupam Saxena, Department of Mechanical Engineering, IIT Kanpur.

Show more

down_ic

Course tags

calendar_ic

Industry domains :

Aerospace , Automotive , Manufacturing

calendar_ic

Engineering Disciplines :

Mechanical , Production , Civil & Structural

Course content
